Carretilla elevadora eléctrica nuevo Maxus dostępny od ręki w Łodzi ! ! ! Elektryczny wózek widłowy 1600kg 3m / Elektrischer Hubwagen 1600 kg 3 Meter / Electric forklift 1600kg 3m/ 1600 kg-os elektromos targonca/ Stivuitor electric 1600 kg 3m

Model 1600

Power Type: Battery

Nominal Load Capacity (kg): 1600

Center of Gravity Distance (mm): 500

Length:

With forks L1 (mm): 3040

Without forks L2 (mm): 1970

Overall Width B (mm): 1000

Height:

Height without lifting frame H1 (mm): 1960

Height of upper frame H2 (mm): 2010

Maximum Lifting Height H3 (mm): 4050

Distance from seat to upper light L3 (mm): 1000

Wheelbase L4 (mm): 1260

Front Overhang Y (mm): 385

Rear Overhang L5 (mm): 365

Front Wheel Tread R (mm): 1010

Rear Wheel Tread P (mm): 100

Minimum Ground Clearance F (mm): 130

Maximum Lifting Height H (mm): 3000

Free Lifting Height H4 (mm): 40

Forks Adjustment S (mm): 1040/200

Minimum Turning Radius WA (mm): 2100

Minimum Drive Width RA (mm): 3785

Frame Angle a/β (°): 6/12

Maximum Lifting Speed without Load (mm/s): 300

Maximum Lifting Speed with Full Load (mm/s): 260

Maximum Speed without Load (km/h): 14

Maximum Speed with Full Load (km/h): 13

Maximum Lifting Angle (%): ≤15

Total Weight (kg): 2650

Drive Wheel 2/2

Tire Type: Pneumatic

Front Tire: 18x7-10

Rear Tire: 16x6-8

Hydraulic Handbrake Pedal

Brake Type: M-Manual

Battery Voltage/Capacity (V/Ah): 48V/230Ah

Drive Motor Power (kW): 5AC

Pump Power (kW): 6.5AC

Operating Time: 5 hours

Charging Time: 7 hours

Charger: 230V
